Commercial kitchen
Leading brand of electrostatic precipitator for commercial kitchen ventilation.
Wholesale double electrostatic precipitator diagram RUIHE Brand
Shipping information:
1 Unit/ wooden case
Model:
DGRH-K-2-14000 / DGRH-K-2-14000U
MOQ:
1 Unit
Payment:
T/T, L/C
Delivery time:
Depends on order quantity
Start Port:
Shenzhen, Guangzhou
Certification:
CE, RoHS, ISO9001:2015
Delivery Time
5-10 days
Start Port
Shenzhen, Guangzhou
Supply Ability
1000 units
Application Scope
RuiZhaoHe's electrostatic precipitator manufacturers can be used in a variety of situations.With rich manufacturing experience and strong production capability, RuiZhaoHe is able to provide professional solutions according to customers' actual needs.RuiZhaoHe's electrostatic precipitator manufacturers have reasonable design and compact structure. They are stable in performance as well as easy in operation and installation.
1. Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd.'s Kitchen Electrostatic Precipitator will further enhance electrostatic precipitator diagram in your business.
2. electrostatic air filter is waterproof and easily cleaned. With a durable aluminum plate, the product excels other models in its corrosion resistance
3. The product is capable of processing a large volume of air flow up to 1500 CMH. RUIHE knows that only quality can win us more customers like you that pays attention to it.
Commercial kitchen electrostatic precipitator （ESP）- Low altitude air emission
As there would be issue if cooking exhaust and nuisance odours can not be control well, it wil lead to complaints from nearby residents and your commercial neighbors. With this in mind, RUIHE double pass ESP series will help you to solve these problem. Grease, smoke and odour particles will be captured efficiently.Over 98% removal efficiency rate ESP ensures air emission at low altitude street level!
Specification
DGRH-K-2-14000 Electrostatic Precipitator (ESP) - double pass >98% removal efficiency
DGRH-K-2-14000U Electrostatic Precipitator (ESP) W/UV-C filter - double pass >98% removal efficiency
| NO. | Model | Air Flow (M³/H) | Cabinet Size L*W*H (MM) | Flange Size (W*H) | Removal efficiency Rate | Wind Resistance (PA) | Power (Watt) | Net Wight (KG) | Remark |
| 1 | DGRH-K-2-14000 | 12000-14000 | 1280*1300*1460 | 1020*1260 | >98% | <100 | 1120 | 376 | W/O UV-C tube, double pass |
| 2 | DGRH-K-2-14000U | 12000-14000 | 1280*1300*1460 | 1020*1260 | >98% | <100 | 2320 | 396 | W/ 12*UV-C tube,double pass |
Application
Commercial kitchen, restaurants, hotels, fast food restaurant, HVAC air purification etc.
Restaurants
Hotels
Advantage
1
1
Dirty air is double pass. Smoke, grease particles removal efficiency rate is over 98%. Allows for discharge at street level and into public spaces outdoors.
1
1
Modular in design: Easy installation, maintenance and cleaning.
1
1
Cost effective & eco-friendly: Long life-span, minimum maintenance energy-saving and space-saving.
1
1
Durable aluminum plate type collector cells. Saving 60-70% power than honeycomb models in the market.
1
1
Durable stainles steel blade ionizers prevent common tungsten wire breakage and replacement, reduce maintenance and replacement cost.
1
1
Intellegent electrostatic power control system: Electric intensity auto-control function ensures the unit maintains a high purification rate after a long time service.
1
1
Safety and Stability: (1) Door-open power-off protection, (2) Over-current, voltage & temperature protection
1
1
Greatly reduces the grease accumulation in the ducts and fire hazard.
1
1
Optional: Photolysis and odour removal efficiently with UV-C filter systems.
Company Features
1. As one of the most well-known exporter, Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd. is going to increase its capacity and grow stronger.
2. A Little Knowledge Is A Dangerous Thing. RUIHE's Kitchen Electrostatic Precipitator, electrostatic precipitator diagram, electrostatic precipitator working principle Are Well Designed And With Competitive Prices. Check Now!
3. Since its entry into the oversea market, Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd. has been adhering to the high standard. Contact!
{{item.score}} Stars
{{item.pre}}%
{{item.nickname ? (item.nickname.slice(0, 2) + '*****') : item.source === 1 ? 'mall buyer' : '--'}}
{{item.comment_time}}
Review in the {{item.country}}
{{itemAttr.params_key}}: {{itemAttr.params_value}}
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
you might like
no data
ABOUT RUIHE (DR. AIRE)
Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd
We are specializing in the design, production and after-sales service of fume purification
equipment and exhaust gas treatment equipment.
ONE-STOP AIR CLEANING MANAGEMENT SOLUTIONS
(1) - Commercial cooking fume odour management
(2) - Industrial exhaust management
(3) - CNC machines oil mist management
