Leading brand of electrostatic precipitator for commercial kitchen ventilation.

RUIHE / DR. AIRE rate scrubbers precipitators and filters for business for home 1

RUIHE / DR. AIRE rate scrubbers precipitators and filters for business for home 2

RUIHE / DR. AIRE rate scrubbers precipitators and filters for business for home

Shipping information:

1 Unit/ wooden case

Model:

DGRH-K-2-31500 / DGRH-K-2-31500U

MOQ:

1 Unit

Payment:

T/T, L/C

Delivery time:

Depends on order quantity

Start Port:

Shenzhen, Guangzhou

Certification:

CE, RoHS, ISO9001:2015

Inquiry

Delivery Time

5-10 days

Start Port

Shenzhen, Guangzhou

Supply Ability

1000 units

Company Advantages
1. The raw material used in RUIHE / DR. AIRE is of high quality and has no any strange smell during use. The product can remove smaller oil particles as small as 0.01 microns
2. The product has a wide application and a great market value. By stacking vertically and horizontally to expand air flow, the product achieves higher removal efficiency
3. This product has good strength. Various types of load and stresses caused by the load are analyzed for choosing the best structure and materials for its strength. The quality of product is officially certified under CE, RoHS and ISO9001:2015
4. It is endowed with convenient features. Its operating features have been carefully studied. The controlling panel is located on the basis of convenient handling. The product can be customized to the developing needs of the customers

RUIHE-Fume Removal rate ESP Oil Fume Machine For Commercial Kitchen

Commercial kitchen electrostatic precipitator （ESP）- Low altitude air emission

RUIHE double pass ESP system is a preffered commercial kitchen air pollution control equipment. Commercial kitchen equipment applictions create grease, smoke and odors. They can be filtered efficiently. Our ESP units are modular designs. It can be stacking together to meet different air flow and removal efficincy requirement.

Specification

DGRH-K-2-31500 Electrostatic Precipitator (ESP) - double pass >98% removal efficiency
DGRH-K-2-31500U Electrostatic Precipitator (ESP) W/UV-C filter - double pass >98% removal efficiency

NO.	Model	Air Flow (M³/H)	*Cabinet Size LWH (MM)*	*Flange Size (WH)**	Removal efficiency Rate	Wind Resistance (PA)	Power (Watt)	Net Wight (KG)	Remark
1	DGRH-K-2-31500	27000-31500	128018352190	1560*1990	>98%	<100	2520	732	W/O UV-C tube, double pass
2	DGRH-K-2-31500U	27000-31500	128018352190	1560*1990	>98%	<100	6120	774	W/ 24*UV-C tube, double pass

Application

Commercial kitchen, restaurants, hotels, fast food restaurant, HVAC air purification etc.

Commercial kitchen

Restaurants

RUIHE-Fume Removal rate ESP Oil Fume Machine For Commercial Kitchen-3

Hotels

Advantage

Dirty air is double pass. Smoke, grease particles removal efficiency rate is over 98%. Allows for discharge at street level and into public spaces outdoors.

Modular in design: Easy installation, maintenance and cleaning.

Cost effective & eco-friendly: Long life-span, minimum maintenance energy-saving and space-saving.

Durable aluminum plate type collector cells. Saving 60-70% power than honeycomb models in the market.

Durable stainles steel blade ionizers prevent common tungsten wire breakage and replacement, reduce maintenance and replacement cost.

Intellegent electrostatic power control system: Electric intensity auto-control function ensures the unit maintains a high purification rate after a long time service.

Safety and Stability: (1) Door-open power-off protection, (2) Over-current, voltage & temperature protection

Greatly reduces the grease accumulation in the ducts and fire hazard.

Optional: Photolysis and odour removal efficiently with UV-C filter systems.

Company Features
1. Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd. successfully grasped the trends to utilize its technology to produce the most popular scrubbers precipitators and filters . One of the most distinguished characteristics of dry scrubber for kitchen exhaust is a longer lifespan than other products.
2. By continuously strengthening hardware construction, RUIHE / DR. AIRE has the capability to provide modular kitchen exhaust with .
3. The high quality of kitchen exhaust oil filter is the most competitive advantage for Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd.. Dongguan Ruizhaohe Environmental Protection Equipment Co., Ltd. guarantee high quality service for its costumers. Ask!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
